PLANET, Ethernet Switch
Planet GSD-504 5-Port 10/100/1000BASE-T Gigabit Ethernet Switch
Planet GSD-504 5-Port 10/100/1000BASE-T Gigabit Ethernet Switch
PLANET GSD-504 Green Networking Switch is specially designed to meet the current trend for energy savings worldwide. The GSD-504, a 5-port Gigabit Ethernet Switch, brings both benefits of energy savings and Gigabit wire-speed performance to home networking, SOHOs, and enterprises.
Energy Savings
The GSD-504 uses a new engine that provides power savings of up to 40% but maintains high-performance efficiency. It incorporates two advanced Green Networking technologies:
- Hibernation Link Down power savings
- Intelligent use of power based on cable length
The Hibernation Link Down power savings goes beyond IEEE specifications to automatically lower power for a given port when it is not linked. With the Hibernation Link Down power-saving technology, the GSD-504 will automatically adjust the power usage of the ports that are shut down or not connected to the network device.
Intelligent use of power uses an intelligent algorithm that actively determines the appropriate power level based on cable length. When the GSD-504 is connected with an Ethernet cable shorter than 20m, a device can obtain maximum power savings because the GSD-504 would automatically detect the Ethernet cable length and diminish power usage. The connected device can substantially reduce the overall power consumption, which makes a significant contribution to energy savings.
Leading Home, SOHO, and Workgroup Users to High-speed Networking Generation
The GSD-504 is designed with modern plastic compact housing and easy to deploy high-speed Gigabit networking in home or SOHO applications. Providing a 10Gbps internal switching fabric, the GSD-504 can handle an extremely large amount of data in a secure topology linking to a backbone or high-capacity servers. The GSD-504 provides a 2K MAC address table and wire-speed packet transfer performance without risk of packet loss. The high data throughput of the device makes it ideal for most Gigabit environments, especially for the network to be upgraded to a Gigabit environment.
SKU: n/a -
Ethernet Switch, PLANET
Planet GSD-504UP 2-Port 10/100/1000T 802.3bt PoE + 2-Port 10/100/1000T 802.3at PoE + 1-Port Gigabit Desktop Switch (External 120 Watts)
Ethernet Switch, PLANETPlanet GSD-504UP 2-Port 10/100/1000T 802.3bt PoE + 2-Port 10/100/1000T 802.3at PoE + 1-Port Gigabit Desktop Switch (External 120 Watts)
Planet GSD-504UP 2-Port 10/100/1000T 802.3bt PoE + 2-Port 10/100/1000T 802.3at PoE + 1-Port Gigabit Desktop Switch (External 120 Watts)
PLANET GSD-504UP is the smallest unmanaged Gigabit PoE switch equipped with two 802.3bt PoE++ ports, two 802.3at PoE+ ports, and one uplink port. With a total PoE power budget of 120 watts and non-blocking data switching performance, the GSD-504UP can fulfill the demand for sufficient PoE power for different applications.
Plug and Play High Power Sourcing SolutionÂ
Complying with the IEEE 802.3bt Power over Ethernet Plus Plus technology, the GSD-504UP provides up to 90 watts of PoE output power, tripling that of the earlier 802.3at plus. With the Legacy function enabled via the DIP switch, it can be backward compatible with 802.3af/at PoE standards to allow users to flexibly deploy standard and high-powered devices simultaneously with no need for software configuration. With data and Power over Ethernet from one unit, the GSD-504UP can reduce cable deployment and eliminate the need for dedicated electrical outlets on the wall, ceiling, or any unreachable place.
Environment-friendly, Fanless Design for Silent Operation
The GSD-504UP comes with a desktop-sized, compact metal housing, making the placement of the unit convenient. It features a ventilated construction in which a cooling fan is not necessary, thereby making its operation noiseless. Moreover, the GSD-504UP is able to operate reliably and stably in any environment without affecting its performance. The deployment of PoE PDs with constant power feeding can be easily and quickly done.
SKU: GSD-504 -
PLANET, Ethernet Switch
Planet IGS-10020HPTÂ Industrial 8-port 10/100/1000T 802.3at PoE + 2-port 1G/2.5G SFP Managed Switch
PLANET, Ethernet SwitchPlanet IGS-10020HPTÂ Industrial 8-port 10/100/1000T 802.3at PoE + 2-port 1G/2.5G SFP Managed Switch
Planet IGS-10020HPTÂ Industrial 8-port 10/100/1000T 802.3at PoE + 2-port 1G/2.5G SFP Managed Switch
Environmentally Hardened Design
PLANET Industrial 8-port Gigabit 802.3at PoE+ Switch, IGS-10020HPT, is equipped with a rugged IP30 metal case for stable operation in heavy Industrial demanding environments. Thus, the IGS-10020HPT provides a high level of immunity against electromagnetic interference and heavy electrical surges which are usually found on plant floors or in curbside traffic control cabinets.
Being able to operate under a wide temperature range from -40 to 75 degrees C, the IGS-10020HPT can be placed in almost any difficult environment. The IGS-10020HPT also allows either DIN rail or wall mounting for efficient use of cabinet space.
Redundant Ring, Fast Recovery for Critical Network Applications
The IGS-10020HPT supports redundant ring technology and features a strong, rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology, Spanning Tree Protocol (802.1s MSTP), and redundant power input system into customer’s industrial automation network to enhance system reliability and uptime in harsh factory environments.
SKU: n/a
